Micro Commercial Components (MCC) MCG4D8N04Y 40V Low RDS(on) N-Channel MOSFETs

Micro Commercial Components (MCC) MCG4D8N04Y 40V Low RDS_(on) N-Channel MOSFETs operate using Split Gate Trench (SGT) power MOSFET technology. These MOSFETs offer a 4.8mΩ maximum RDS_(on) in a compact PDFN3333 package and are available in industrial and automotive grades. The MCG4D8N04Y MOSFETs feature a high-density cell design for low RDS_(on). These MOSFETs can operate at junction temperatures of -55°C to 175°C, even in extreme environmental conditions. The MCG4D8N04Y MOSFETs are lead-free and RoHS-compliant. These MOSFETs are used in applications such as Battery Management Systems (BMS), motor drives, inverter systems, solar inverters, wind turbine controllers, and in-vehicle infotainment systems.

Features

Split Gate Trench (SGT) power MOSFET technology
High-density cell design for low R_DS(on)
4.8mΩ maximum R_DS(on)
-55°C to 175°C operating junction temperature range
Compact PDFN3333 package
AEC-Q101 qualified (MCG4D8N04YHE3)

Improved efficiency
±20V gate-source voltage
40V drain-source voltage
Epoxy meets UL 94V-0 flammability rating
Moisture Sensitivity Level 1 (MSL 1)

Applications

Industrial:
- Battery Management Systems (BMS)
- Motor drives
- DC-DC converters
Automotive:
- Advanced Driver Assistance Systems (ADAS)
- In-vehicle infotainment systems
- Thermal management systems

Consumer:
- Power supply units
- Inverter systems
Renewable energy:
- Solar inverters
- Wind turbine controllers
